EPG-002: Meet the EPG-002 IIoT Gateway: A powerhouse in facilitating connections and communications. This device comes loaded with Node-RED and enhanced support for RS-485 port connections, making it more versatile in device integration.
HARDWARE | |
---|---|
CPU | Quad-Core Arm Processor |
RAM | 2GB |
Storage | 8GB EMMC |
Wireless | LTE Cat4, WiFi |
RTC | Real Time Clock |
Interface | 1 x Gigabit Lan Port, 4 x USB, 2 x RS485, 2 x RS232, 1 x HDMI, 6 x Digital(I/O) |
Rated Voltage | DC 9~12 V |
Rated Power | 5W |
Storage | 8GB EMMC |
Power Protection | Anti-Static, Anti-Surge, Anti-Reversei |
Certification | CE / ROHS |
SOFTWARE | |
Network Protocol | MQTT / HTTP / TCP / UDP / WEBSOCKET |
OS | Ubuntu |
Edge Computing | Support drag and drop programming Support zero-code development Support JavaScript development |
EPG-002: Meet the EPG-002 IIoT Gateway: A powerhouse in facilitating connections and communications. This device comes loaded with Node-RED and enhanced support for RS-485 port connections, making it more versatile in device integration.
EPG-002
Length: 125mm
Width: 157mm
Height: 28mm
Commodo elit at imperdiet dui accumsan sit amet. Aliquam eleifend . Eu lobortis elementum nibh tellus molestie nunc. A condimentum vitae sapien pellentesque habitant morbi tristique senectus. In ornare quam viverra orci sagittis.
Commodo elit at imperdiet dui accumsan sit amet. Aliquam eleifend . Eu lobortis elementum nibh tellus molestie nunc. A condimentum vitae sapien pellentesque habitant morbi tristique senectus. In ornare quam viverra orci sagittis.
HARDWARE | |
---|---|
CPU | Quad-Core Arm Processor |
RAM | 2GB |
Storage | 8GB EMMC |
Wireless | LTE Cat4, WiFi |
RTC | Real Time Clock |
Interface | 1 x Gigabit Lan Port, 4 x USB, 2 x RS485, 2 x RS232, 1 x HDMI, 6 x Digital(I/O) |
Rated Voltage | DC 9~12 V |
Rated Power | 5W |
Storage | 8GB EMMC |
Power Protection | Anti-Static, Anti-Surge, Anti-Reversei |
Certification | CE / ROHS |
SOFTWARE | |
Network Protocol | MQTT / HTTP / TCP / UDP / WEBSOCKET |
OS | Ubuntu |
Edge Computing | Support drag and drop programming Support zero-code development Support JavaScript development |
HARDWARE | |
---|---|
CPU | Broadcom BCM2711, Quad-core A72 (ARM v8)@ 1.5 GHz |
Memory | 2GB (1GB/4GB/8GB optional) LPDDR4 |
Flash | 8GB (16GB/32GB optional) eMMC |
Ethernet | Gigabit Ethernet x 1, (1-WAN or 1-LAN Configurable) |
Cellular | Lora WAN |
Physical Ports | 2 x DI, 2 x DO |
Communication Ports | RS-232 x 1,RS-485 x 1, RS-232: TXD, RXD, GND; RS-485: A, B, GND; ESD protection: 15KV |
USB | USB 2.0 x 2 for peripherals, USB-C x 1 for Console |
HDMI | HDMI 2.0 x 1, (Up to 4kp60 video & audio output) |
Power Supply | Wide Range Voltages 9~36V DC/1A |
SOFTWARE | |
Network Protocol | Modbus RTU/TCP, Siemens, OPC UA, HTTP, MQTT, ARP, QoS, SNTP, Telnet, SSH |
Wi-Fi | Dual Band 2.4GHz & 5GHz + Bluetooth 5.0 |
GPS | Cellular Module built-in supported (Optional) |
Applications Support | Modbus RTU, VPN, Router, Firewall, Media Player, Python, Node-RED, Docker |
VPN | Support PLC remote upload and download (Network Port) |
